Methodology

How ASTRO-SCAN is engineered. Principles, sources, and decisions.

1. Project context

ASTRO-SCAN is an independent space observation platform engineered solo from Tlemcen, Algeria. It started as a personal sandbox for real-time astronomy and grew into a distributed system covering live spacecraft tracking, space weather, situational awareness, family safety telemetry, and astrophysical observation. Every component is deployed in production on a Hetzner VPS in Hillsboro, Oregon.

The platform is built without external funding, without a team, and without proprietary data. All sources are public APIs from government agencies and open scientific networks.

2. Engineering principles

Honesty over decoration. Every metric shown to the user is either a live value streamed from a public upstream, or a derivation computed transparently from live values. No synthetic placeholder is ever presented as real data, even when masked with a "SIM" badge. In v2.7.0 alone, 253 lines of decorative HTML were deleted from the Situational Awareness module because they could not be wired to a real source.

Sourced or removed. If a data point cannot be tied to a public, auditable upstream, it does not exist in the interface. This is not a UX choice. It is an engineering ethic. ESA-grade systems do not guess.

Microservices with zero coupling. Each major module (Sentinel, Situational Awareness, AEGIS) runs as its own systemd service on its own port, behind nginx reverse-proxy. A failure in one module cannot cascade. A new module ships without touching legacy code.

Privacy by design. Sentinel uses MaxMind GeoLite2 locally (no third-party lookup), stores zero-knowledge country counters, and respects a hard TTL of 12 hours maximum on shared location data. No tracking pixels. No analytics from external providers.

Hardening as default. Every systemd service runs with NoNewPrivileges, ProtectSystem=strict, PrivateTmp, ProtectHome, and explicit ReadWritePaths whitelists. SSH keys only, no passwords. Secrets exclusively via environment variables, never committed.

3. Data sources

All data displayed comes from one of the following public sources. Each source is cached server-side to respect upstream rate limits.

Domain	Source	License
ISS orbit (TLE)	AMSAT nasabare.txt	Public
Geomagnetic Kp / F10.7 / X-Ray	NOAA SWPC	US Gov public domain
Space weather alerts	NOAA SWPC Alerts	US Gov public domain
Global earthquakes (24h)	USGS Earthquake Hazards	US Gov public domain
Aircraft state vectors	OpenSky Network	CC-BY 4.0 (research)
Astronomy picture of the day	NASA APOD	Public
Earth imagery	NASA Blue Marble / Black Marble (GIBS)	Public
GeoIP country resolution	MaxMind GeoLite2 (local)	CC-BY-SA 4.0

4. Derived signals

Some indicators are not directly streamed. They are computed in real time from live inputs. Every formula is documented, auditable, and deterministic. The Global Threat Index displayed in Situational Awareness is computed as follows:

threat_index =
    0.35 * normalize(noaa_kp, 0, 9)              // Geomagnetic storm
  + 0.20 * normalize(log10(xray_wm2), -8, -3)    // Solar flare X-ray
  + 0.25 * seismic_score                         // USGS 24h aggregate
  + 0.10 * air_traffic_density                   // OpenSky saturation
  + 0.10 * min(48, tle_age_hours) / 48 * 100     // Data freshness

The seismic sub-score is the estimated shaking intensity at the observatory (Tlemcen), not a count of global earthquakes. A former magnitude-weighted world count made a distant M7 saturate the term to 100 even when nothing was felt on site; it is replaced (SG-A0012) by a site-local intensity. For each event, the Modified Mercalli Intensity (MMI) expected at the observatory is computed with the USGS « Did You Feel It » attenuation relation (Bakun and colleagues), active-crust version:

MMI = 5.07 + 1.09 * M - 3.69 * log10(D_hypo)
D_hypo = sqrt(surface_distance_km^2 + depth_km^2)   // hypocentral, conservative
MMI < 1  ->  0 (not felt) ; MMI bounded to [0, 12]
seismic_score = max(MMI over 24h) / 12 * 100        // explicit linear scale -> [0, 100]

Estimated intensity, never measured. The hypocentral distance is chosen because it is conservative (it never over-estimates intensity) and reduces to the epicentral distance for a shallow event. The linear MMI / 12 scale is used because MMI is already an ordinal intensity scale [0–12]; a linear map preserves its meaning and stays auditable (MMI 12 total destruction → 100, MMI 0 not felt → 0). A distant M7 that is not felt contributes 0; a nearby M3.5 that is felt contributes. Events without usable coordinates or depth are excluded from the calculation and counted separately (excluded_no_coords), never guessed.

Honesty — known limits. This relation is calibrated for the Western United States (shallow active crust) and applied to the Mediterranean for lack of a regionally calibrated relation — the USGS itself notes these relations have regional dependencies and encourages operators to develop their own. It ignores site effects (soil amplification). Its uncertainty is on the order of 0.8 MMI unit. Observatory coordinates come from the single source of truth (app/constants/observatory.py), never hardcoded.

5. Stack

Backend: Python 3.12, Flask (main app), FastAPI (Situational Awareness microservice), httpx, asyncio, uvloop, gunicorn, uvicorn.
Frontend: vanilla JavaScript (no framework bloat), CesiumJS for 3D globes, Chart.js for time-series, WebSocket for real-time telemetry.
Astronomy: Skyfield (SGP4 propagation), Astropy (ephemerides), N2YO (ISS pass predictions).
Infrastructure: Hetzner VPS Hillsboro Oregon US-West, nginx (TLS via Porkbun DNS-01), systemd with hardening, Redis (caching facade).
Quality: pytest smoke + unit + coverage on Python 3.11 + 3.12, GitHub Actions CI on every push, semantic versioning with descriptive tags.

6. Versioning and operations

Releases follow semantic versioning. The current major release is v2.7.0-mission-control-live, which adds the Situational Awareness module. Each release tag carries a descriptive suffix so the git log itself reads as an engineering narrative.

Production deployment is reproducible from the GitHub repository: clone, install dependencies, set environment variables, enable systemd units. The repository at github.com/za1974ria/astroscan is the single source of truth. CI runs on every push.

7. What this platform is not

ASTRO-SCAN is not a research instrument. It is not a substitute for ESA Space Safety Programme assets, NOAA real-time alerts, or USGS seismic monitoring. It is an aggregator and visualizer. Operational decisions should always be made against the upstream sources directly, which are listed and linked in this document.

Methodology last revised: 16 May 2026 with the v2.7.0-mission-control-live release. Engineered by Zakaria Chohra from Tlemcen, Algeria. Contact via github.com/za1974ria.
